Flows

Flows are based on node-red workflows and are typically used as example / demonstrator (fully functional) applications used with a single Tag style and single Node style (typically Art-Access Node if access control or alerting is required). Atlas is used if multiple Tag / Node styles are required.

Available in one of three options, Secure, Sense or Store

Requires a node-red platform.

Secure monitors Tag reads and looks up a corresponding asset record in a database. If the asset is authorised then activates the relay in an Art-Access Node.

Sense (shown below) monitors a Sensor Tag and displays the reading in a gauge. An upper and lower setpoint trigger outputs in an Art-Access Node if the setpoints are reached or exceeded.

Store stores datetime stamped Tag reads in a database allowing database reporting tools to determine when Tag reads occurred and the status of the asset (whether any Tag alerts occurred).
